Ice Dimensions (WxDxH)

37 x 30 x 13 mm

External Dimensions (WxDxH)

Body : 762 x 712 x 840 mm /
Leg Height: 152mm

Packed Dimensions (Wxdxh)

845 x 800 x 955 mm

Weight (NETT/GROSS)

70 KG / 85 KG

Amperage / Starting Amperage

4.5A / 19A

Electrical Consumption

774 W

Refrigerant Charge

R404a

Heat Rejection (AT32°C/WT21°C)

1650W (1420 kcal/h)

Ice Production per 24h (15MM)

(AT10°C/WT10°C)

128 KG

(AT21°C/WT15°C)

115 KG

(AT32°C/WT21°C)

102 KG

Water Consumption Per 24h(At21°C/Wt15°C)

0.40 m3

3.5L / 1KG ICE

Ice Production (AT21°C/WT15°C)

FREEZE CYCLE TIME

24 MIN

PER CYCLE

2.1 KG / 238 PCS

Storage

55 KG

Operating Conditions:

Voltage Range: 198V-254V • Ambient Temperature: 1°-40°C• Water Supply: 5°-35°C / 0.07-0.8 Mpa / 7.25-116 PSI • AC Supply Voltage: 1/220-240V / 50 Hz
